eBPF Linux Kernel Subsystem

The Extended Berkeley Packet Filter (eBPF) is a revolutionary in-kernel virtual machine and execution environment capable of running sandboxed programs within the Linux kernel without altering kernel source code or loading external kernel modules. By leveraging a strict in-kernel verification engine that enforces type safety, memory bounds, and program termination invariants, eBPF bridges user-space intent and kernel-space observability/networking at native execution speeds via Just-In-Time (JIT) compilation.

sudo apt-get update && sudo apt-get install -y
    clang
    llvm
    libbpf-dev
    linux-tools-common
    linux-tools-generic
    bpftool
ls -l /sys/kernel/btf/vmlinux

#include <linux/bpf.h>
#include <bpf/bpf_helpers.h>
#include <bpf/bpf_tracing.h>

char LICENSE[] SEC("license") = "GPL";

struct {
    __uint(type, BPF_MAP_TYPE_HASH);
    __type(key, __u32);
    __type(value, __u64);
    __uint(max_entries, 1024);
} packet_count_map SEC(".maps");

SEC("xdp")
int count_packets(struct xdp_md *ctx) {
    __u32 key = 0;
    __u64 *val;

    val = bpf_map_lookup_elem(&packet_count_map, &key);
    if (val) {
        __sync_fetch_and_add(val, 1);
    } else {
        __u64 init_val = 1;
        bpf_map_update_elem(&packet_count_map, &key, &init_val, BPF_ANY);
    }

    return XDP_PASS;
}

clang -O2 -g -target bpf -c packet_counter.bpf.c -o packet_counter.bpf.o
bpftool prog load packet_counter.bpf.o /sys/fs/bpf/packet_counter

bpftool map show
bpftool map dump name packet_count_map

Architectural Design & Verifier Mechanics

The eBPF core architecture revolves around a register-based virtual machine containing 10 general-purpose 64-bit registers, a frame pointer, and a 512-byte stack. Prior to JIT compilation into native machine code (x86_64, ARM64, etc.), every loaded program must pass through the in-kernel eBPF Verifier. The verifier constructs a directed acyclic graph (DAG) of the program's control flow and simulates execution paths to guarantee memory safety, initialization of all read registers, strict stack bounds checking, and absolute loop termination (bounded loops are permitted via static analysis or explicit instruction bounds).

BPF Maps and Data Structures

Communication between kernel-space eBPF programs and user-space orchestrators occurs via BPF Maps—efficient, concurrent key-value or array data structures stored in kernel memory. Common map types include BPF_MAP_TYPE_HASH, BPF_MAP_TYPE_ARRAY, BPF_MAP_TYPE_RINGBUF (for high-throughput streaming data), and BPF_MAP_TYPE_PERCPU_HASH to minimize lock contention across multi-core architectures. Access complexity for hash maps is O(1) average case, optimized via internal kernel hashtable implementations.

CO-RE (Compile Once – Run Everywhere)

Older eBPF implementations required kernel headers matching the running target kernel, breaking portability across kernel upgrades. Modern eBPF utilizes BTF (BPF Type Format) and relocation records. BPF CO-RE allows developers to compile a single BPF object file that dynamically resolves kernel structure offset changes at load time via libbpf, matching local kernel field layouts automatically.
